Name：SL-VS01 4ohm 10-25W transducer vibration speaker driver 50mm
Describe：
4ohm 10-25W transducer vibration speaker driver 50mm
Content：
vibration speaker 4ohm 20W
|
Our Model No. |
SL-VS01 |
Product Model No： |
|
|||
|
1 |
Applicable Scope |
|||||
|
1.1 |
Type |
Resonance speaker |
||||
|
1.2 |
Dimensions |
50 mm |
||||
|
1.3 |
Power |
Nominal input 15 W, Maximum input 25W |
||||
|
2 |
mechanical specification |
|||||
|
2.1 |
magnet magnet |
Size：25*3.5 N40 Size：25*3.5 N40
|
|
Material ： |
||
|
2.2 |
Total Weight |
0.5kg |
||||
|
3 |
Electrical specification |
|||||
|
3.1 |
Nominal Impedance |
4Ω±15% test @200Hz 1 v |
||||
|
3.2 |
Lowest Resonance Frequency |
58Hz±20% (@ 1.0 V) |
||||
|
3.3 |
Output sound Pressure Level |
85±3 dB (100、400、800、12000Hz 的 medium value @ 1m 10w) |
||||
|
3.4 |
Effective Frequency Band |
Fo ~ 20KHz ( average sensitivity fall 10dB )@2.0V 10 W
|
||||
|
3.5 |
Distortion |
5% less @ 5W 1000Hz |
||||
|
3.6 |
Sine Wave Test |
9V 60~2.0K HZ Must be normal at sine wave |
||||
|
3.7 |
|
|
||||
|
|
|
|||||
|
4.1 |
Load Test |
Must be normal after load test :pink noise 10W 48 hours |
||||
|
|
|
|
||||
|
|
|
|
||||
|
|
|
|
||||
